FIAT Bravo · 1.9 TD 75 SX · Hatchback · 1998 ‐ 2001

From 1998 Fiat started manufacture of automobiles model Bravo, modification of 1.9 TD 75 SX and finished it in 2001. This three-door hatchback has a length of 4 meters, weight 1.1 tons and is destined to sit 5 passengers including the driver.

«Bravo 1.9 TD 75 SX» have a front wheel drive car with a 5-speed manual gearbox. 4-cylinders diesel motor with «indirect injection system» can generate output 75 horsepower at 4200 rmp, which allows you to accelerate the auto for 15.1 seconds to 100 km/h and achieve maximum speed of 165 km/h.

Fuel tank capacity of this auto is 50 l of diesel, thereby when normal fuel consumption is 6.3 liters per 100 km (5.1 l on the highway, 8.5 liters in the urban), that allows to go approximately 794 km unrefuelled.

The front wheels of this automobile have disks, 257 mm brakes and attached to the chassis by dint of suspension «MacPherson, independent, coil springs» and equipped with anti-roll bar. Back wheels have drums, 203 mm brakes and attached to the undercarriage through suspension type «Transverse arms, independent, coil springs» and equipped with stabilizer bar. Tires have the next size - 175/65TR14.

In conformity with the data of Euro NCAP crash test, this model of Fiat Bravo got the 2 quantity of stars. In addition to passive safety (driver, passenger airbags), it is also has dynamic safety such as ABS.

Specifications of Fiat Bravo 1.9 TD 75 SX

COMPARE THIS CAR

Common data
MakerFiat SeriesBravo Model1.9 TD 75 SX Production year1998 ‐ 2001 Body typeHatchbackDoors number3Number of seats5FuelDieselDriveFrontTransmission typeManualNumber of gears5

Performance
Maximum speed165 km/h
SIMILAR
Acceleration to 100 km/h15.1 seconds
SIMILAR
Fuel consumption     - average6.3 l per 100 km
SIMILAR
    - in the city8.5 l per 100 km    - on the highway5.1 l per 100 kmFuel tank volume50 lAverage cruising range794 km

Chassis
Tire size175/65TR14Front breaksdisks, 257 mmRear breaksdrums, 203 mm
Front suspension
MacPherson, independent, Coil springs
Rear suspension
Transverse arms, independent, Coil springs
Front stabilizerYesRear stabilizerYesTurning radius10.4 m

Options
Frontal test impactRating: 2 of 5Airbags     - driver    - passengerABSCentral door lockingElectric windowsPower steering

Exterior options
Xenon headlampsAuto-switching of lightBurglar alarms
Engine
Volume1910 cc
SIMILAR
CylindersL4Valves2Valve operationOHCPower75 hp (4200 rpm)
SIMILAR
Torque147 Nm (2750 rpm)
SIMILAR
Compression20.7 : 1Bore and stroke82,0 x 90,4 mmFuel systemIndirect injectionTurbochargingYesEmissions of CO2168 g/km

Weights and loads
Curb weight1120 kg
SIMILAR
Max permitted weight1645 kg
SIMILAR
Max payload525 kgMax load on roof100 kgMax noseweight70 kgMax braked trailer mass1300 kgMax unbraked trailer mass400 kg

External dimensions
Length4025 mm
SIMILAR
Width1755 mm
SIMILAR
Height1411 mm
SIMILAR
Front track1439 mmRear track1441 mmWheelbase2540 mm
SIMILAR

Internal dimensions
Luggage volume280 - 1030 lRear headspace9680 mm

Interior options
Seats options:     - heigh adjustment    - rear headrests    - rear foldableOdometerCoolant temperatureRudder adjustmentAudio system
